Tandem / Continuous Cold Rolling Mill

Tandem / Continuous Cold Rolling Mill

Main features
The continuous rolling mill is of several mills laid out in the line. The strips pass the mills continuously. The quantity of rolling passes equal to the quantity of mill stands. Compared with reversing mill, continuous rolling mill has high-efficiency, good quality and high automation, so that it suits for production with high yield. We can provide two-stand cold rolling mill, three-stand cold rolling mill, four-stand cold rolling mill and five-stand cold rolling mill equipped with hydraulic screw-down AGC and automatic thickness gauge, and applied with the technology of endless rolling and automatic welding.

Typical Models and Technical parameters

Mill Model
Material thickness
Product thickness
Max rolling speed
Three-stand
2.0~3.0mm
0.6~1.2mm
240m/min
Four-stand
2.0~4.0mm
0.5~1.2mm
300m/min
Five-stand
2.75~4.0mm
0.5~1.2mm
300m/min
