I. Vacuum Tube Induction Heating Equipment

This type of heating equipment has the vacuum tube as the power source. With SCM as the core, it forms a intellective control system capable of voltage regulation, oscillation, and protection, which enjoys the merits of simple and reliable circuit, easy operation and maintenance.

Composition: step-up transformer, power supply cabinet, oscillating cabinet, capacitor cabinet, operator console, welding transformer, and cooling system.

They are widely used in welding, melting and refining, quenching and tempering, annealing, brazing and soldering, sintering, holding and pouring systems for metal and material processing including steel, iron, aluminum, copper, brass, zinc, precious metals, silicon and graphite, etc.

Power: 60KW-1500Kw
Frequency: 20 kHz-1500 kHz



Vacuum Tube Generator

 Corner Annealing




Bar Annealing

MF Seam Annealing







 HF Tube Welding

 HF/MF Quenching


II. KGS Series High Power DC Power Supply Cabinet

KGS series high power DC power supply has the thyristor as a key part of the 3-phase voltage regulator. With SCM as the core, it forms a intellectual control system capable of voltage regulation and rectification. The PLC enables accurate control of heating temperature, heating power, stand-by time and cooling time so as to ensure the heating technology, and the HMI (touch screen type) facilitates setting of these parameters. The whole system enjoys the merits of high efficiency, simple and reliable circuit, and easy operation and testing. This improved technique helps the manufacture save significant power and also further improve the product quality.

Output DC voltage: 6V-440V
Output DC current: 100A-12,000A

III. CNC & PLC Quenching System

1. CNC Quenching System
The CNC quenching system is a complete set of equipment featuring high-precision and high-efficiency control. It integrates quenching machine, computer, driver, motor, and the technique of auto-control, auto-detection, and auto-analysis. It basically consists of processing program, CNC system, servo system, auxiliary control equipment, feedback system and the quenching machine.

The application of CNC system greatly improves the precision of the machine’s operating movement as well as the precision of controlling, thus the whole dynamic performance. Its quenching program is in international standard language and very easy to learn, which facilitates parameter resetting of the operator.

2. PLC Quenching System
The PLC system enjoys universality, good flexibility and high reliability. The program is simple and easy to learn. The operator can easily change the parameter setting to meet requirements of different work pieces.

IV. Water Cooling System

The water-water cooling system adopts a plate type heat exchanger of special corrugated structure, where the soft water is formed into turbulent flows at a low speed, thus the heat exchanging effect is strengthened. The whole design allows small space occupied, easy assembly/disassembly, and high exchanging efficiency. The cooling water is recycled water supplied from out of this cooling system, so continuous cooling is possible.
